Philips Semiconductors
UM_1SPP
BGB203 BT 2.0 Serial Port Profile Module User’s Guide
value for the local Bluetooth device. Note that if the Class of Device is
set that it will not be saved to Flash (unless the save to Flash command
is used afterward).
Format:
AT+BTCOD=<COD>
where,
<COD> is an integer value (0 – 16777215) of a hexadecimal
value (preceded by “ \x ” or “ \X ” without the quotation marks
0x000000 – 0xFFFFFF) which represents the current Bluetooth
Class of Device value to write to the device.
or one of the following to query the current Class of Device value:
AT+BTCOD?
AT+BTCOD
Results:
If a query is performed, the output will be the following format:
+BTCOD: <COD>
where,
<COD> is a 6 digit ASCII coded hexadecimal value representing
the Class of Device. Note that this value is not preceded with
the “ \x ” or “ \X ” prefix.
Immediately following the above output, the response will be the result
code (either OK or ERROR ).
If a query was not performed (i.e. the Class of Device was set) then the
result will simply consist of the result code (either OK or ERROR ).
Example:
AT+BTCOD?
+BTCOD: 001F00
OK
AT+BTCOD=\x123456
OK
+BTLNM – read/write local Bluetooth device name
Description:
This command is used to query (or set) the Bluetooth device name value
for the local Bluetooth device. Note that if the device name is set that it
will not be saved to Flash (unless the save to Flash command is used
afterward).
? Koninklijke Philips Electronics N.V. 2005
All rights are reserved. Reproduction in whole or in part is prohibited without the prior
written consent of the copyright owner. The information presented in this document does
not form part of any quotation or contract, is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under
patent- or other industrial or intellectual property rights.
Date of release:21 Dec 2005
Published in The Netherlands
